2442 [Plain2: SzCor: BW] DFU
Plain 2: Size Correction: BW Printing Mode
Adjusts the size correction coefficient of the plain 2 paper for the paper transfer roller
current for each paper size. SP2440 and SP2441 are multiplied by these SP values.
Std: 260 mm/sec, Low: 85mm/sec
2-442-001 PTr:Std:1Sid:S1 *ENG [100 to 995 / 100 / 5 %/step]
S1 size ≥ 194 mm (Paper width)
2-442-002 PTr:Std:2Sid: S1 *ENG
2-442-003 PTr:Low:1:S1 *ENG
2-442-004 PTr:Low:2:S1 *ENG
2-442-005 PTr:Std:1Sid:S2 *ENG [100 to 995 / 135 / 5 %/step]
194 mm > S2 size ≥ 165 mm
(Paper width)
2-442-006 PTr:Std:2Sid:S2 *ENG [100 to 995 / 200 / 5 %/step]
194 mm > S2 size ≥ 165 mm
(Paper width)
2-442-007 PTr:Low:1:S2 *ENG [100 to 995 / 135 / 5 %/step]
194 mm > S2 size ≥ 165 mm
(Paper width)
2-442-008 PTr:Low:2:S2 *ENG [100 to 995 / 200 / 5 %/step]
194 mm > S2 size ≥ 165 mm
(Paper width)
2-442-009 PTr:Std:1Sid:S3 *ENG [100 to 995 / 135 / 5 %/step]
165 mm > S3 size ≥ 139 mm (Paper width)
2-442-010 PTr:Std:2Sid:S3 *ENG [100 to 995 / 390 / 5 %/step]
165 mm > S3 size ≥ 139 mm (Paper width)
2-442-011 PTr:Low:1:S3 *ENG [100 to 995 / 135 / 5 %/step]
165 mm > S3 size ≥ 139 mm (Paper width)
2-442-012 PTr:Low:2:S3 *ENG [100 to 995 / 390 / 5 %/step]
165 mm > S3 size ≥ 139 mm (Paper width)
Engine SP Mode Tables - SP2000
321
