2-461-009 PTr:Std:1Sid:S3 *ENG [100 to 600 / 140 / 5% /step]
165 mm > S3 size ≥ 139 mm (Paper
width)
2-461-011 PTr:Low:1:S3 *ENG [100 to 995 / 135 / 5% /step]
165 mm > S3 size ≥ 139 mm (Paper
width)
2-461-013 PTr:Std:1Sid:S4 *ENG [100 to 995 / 220 / 5% /step]
139 mm > S4 (Paper width)
2-461-015 PTr:Low:1:S4 *ENG [100 to 995 / 220 / 5% /step]
139 mm > S4 (Paper width)
2462 [Thin: SzCor: FC] DFU
Thin: Size Correction: FC Printing Mode
Adjusts the size correction coefficient of the thin paper for the paper transfer roller
current for each paper size. SP2453 and SP2457 are multiplied by these SP values.
Std: 260 mm/sec, Low: 85mm/sec
2-462-001 PTr:Std:1Sid:S1 *ENG [100 to 995 / 100 / 5% /step]
S1 size ≥ 194 mm (Paper width)
2-462-003 PTr:Low:1:S1 *ENG
2-462-005 PTr:Std:1Sid:S2 *ENG [100 to 995 / 135 / 5% /step]
194 mm > S2 size ≥ 165 mm
(Paper width)
2-462-007 PTr:Low:1:S2 *ENG
2-462-009 PTr:Std:1Sid:S3 *ENG [100 to 995 / 135 / 5% /step]
165 mm > S3 size ≥ 139 mm (Paper
width)
2-462-011 PTr:Low:1:S3 *ENG
2-462-013 PTr:Std:1Sid:S4 *ENG [100 to 995 / 220 / 5% /step]
139 mm > S4 (Paper width)
2-462-015 PTr:Low:1:S4 *ENG
Engine SP Mode Tables - SP2000
331
