2-715-009 PTr:Std:1Sid:S3 *ENG [1 to 100 / 14 / 1 /step]
165 mm > S3 size ≥ 139 mm (Paper
width)
2-715-010 PTr:Std:2Sid:S3 *ENG [1 to 100 / 5 / 1 /step]
165 mm > S3 size ≥ 139 mm (Paper
width)
2-715-011 PTr:Low:1:S3 *ENG [1 to 100 / 10 / 1 /step]
165 mm > S3 size ≥ 139 mm (Paper
width)
2-715-012 PTr:Low:2:S3 *ENG [1 to 100 / 5 / 1 /step]
165 mm > S3 size ≥ 139 mm (Paper
width)
2-715-013 PTr:Std:1Sid:S4 *ENG [1 to 100 / 14 / 1 /step]
139 mm > S4 (Paper width)
2-715-014 PTr:Std:2Sid:S4 *ENG [1 to 100 / 13 / 1 /step]
139 mm > S4 (Paper width)
2-715-015 PTr:Low:1:S4 *ENG [1 to 100 / 10 / 1 /step]
139 mm > S4 (Paper width)
2-715-016 PTr:Low:2:S4 *ENG [1 to 100 / 12 / 1 /step]
139 mm > S4 (Paper width)
2716 [MThick:SzEvCor:FC] DFU
Adjusts the size correction coefficient for the paper transfer roller current for each
paper size. SP2703 and SP2707 are multiplied by these SP values.
Standard: 260mm/sec, Low: 85mm/sec
2-716-001 PTr:Std:1Sid:S1 *ENG [1 to 100 / 7 / 1 /step]
S1 size ≥ 194 mm (Paper width)
2-716-002 PTr:Std:2Sid:S1 *ENG [1 to 100 / 43 / 1 /step]
S1 size ≥ 194 mm (Paper width)
2-716-003 PTr:Low:1:S1 *ENG [1 to 100 / 37 / 1 /step]
S1 size ≥ 194 mm (Paper width)
Engine SP Mode Tables - SP2000
365
