3321 [Vsg Adjust: Exe.]
3-321-010 P/TM Sensor All ENG Execute the ID sensor initialization setting
for all sensors
3322 [Vsg Adj. Rslt:Vsg]
Displays the result value of the Vsg adjustment for each sensor.
3-322-001 Vsg reg: Bk *ENG [0 to 5.5 / 0 / 0.01 V/step]
3-322-002 Vsg reg: C *ENG
3-322-003 Vsg reg: M *ENG
3-322-004 Vsg reg: Y *ENG
3-322-005 Vsg dif: C *ENG
3-322-006 Vsg dif: M *ENG
3-322-007 Vsg dif: Y *ENG
3-322-008 Vsg TM (Front) *ENG
3-322-009 Vsg TM (Center) *ENG
3-322-010 Vsg TM (Rear) *ENG
3325 [Vsg Adjust Result]
Displays the result of the Vsg adjustment.
The displayed numbers mean the result of each sensor (sensor for Front, sensor for Bk,
sensor for Cyan, sensor for Center, sensor for Magenta, sensor for Yellow and sensor
for Rear).
Engine SP Mode Tables - SP3000
409
