3514 [Env Disp:Job End]
Displays the environmental conditions at the last job.
These are used for process control execution timing.
3-514-001 Temperature *ENG [-1280 to 1270 / 0 / 0.1°C/step]
3-514-002 Relative Humidity *ENG [0 to 1000 / - / 0.1%RH/step]
3-514-003 Absolute Humidity *ENG [0 to 1000 / - / 0.1 g/cm
3
/step]
3515 [Exec Intvl:Disp]
Displays the current interval for process control execution.
When the machine calculates the timing for process control, it uses a number of
conditions. These are the results after considering all the conditions.
3-515-001 Job End:ProCon:BW *ENG [0 to 2000 / 500 / 1 page/step]
3-515-002 Job End:ProCon:FC *ENG [0 to 2000 / 200 / 1 page/step]
3-515-003 Intrrpt:ProCon:BW *ENG [0 to 2000 / 500 / 1 page/step]
3-515-004 Intrrpt:ProCon:FC *ENG [0 to 2000 / 200 / 1 page/step]
3516 [Refresh Mode] DFU
While making prints with low coverage, the developer is agitated with less toner
consumption and the toner carrier attraction tends to increase. This may cause low
image density or poor transfer (white dots). To prevent this, the coagulated toner or
overcharged toner has to be consumed by performing the refresh mode.
3-516-001 Dev.MRotatDspl:Bk *ENG [0 to 1000 / 0 / 0.1 m/step]
3-516-002 Dev.MRotatDspl:C *ENG
3-516-003 Dev.MRotatDspl:M *ENG
3-516-004 Dev.MRotatDspl:Y *ENG
3-516-005 Rotation Thresh *ENG [0 to 1000 / 0.1 / 1 m/step]
5. System Maintenance Reference
414
