Exe Exe 0 1 0
HLT A5 0 0 1
A6 A6 0 0 0
*1: The machine detects either 11" x 81/2" LEF or A4 LEF, depending on the setting of SP
5-131-001.
*2: The machine detects either B5 LEF or 10.5" x 7.25" LEF, depending on the setting of SP
5-131-001.
Table 2: Paper Height Sensor
0: Deactivated, 1: Activated (actuator inside sensor)
Remaining paper Paper height sensor 1 Paper height sensor 2
Full ~ 350 0 0
350 ~ 150 1 0
150 ~ 50 1 1
50 ~ 0 0 1
Output Check Table
Printer
5804 Display Description
5-804-003 DRMT_BK:260mm/s (Drum Motor: K) -
5-804-004 DRMT_BK:182mm/s (Drum Motor: K) -
5-804-005 DRMT_BK:85mm/s (Drum Motor: K) -
5-804-010 FUMT:260mm/s (Fusing Motor) -
5-804-011 FUMT:182mm/s (Fusing Motor) -
5-804-012 FUMT:85mm/s (Fusing Motor) -
Input Check/ Output Check
535
