Ricoh Aficio SP C440DN

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
230
-003
D FGATE ON error: M
The PFGATE ON signal does not assert within 5 seconds after processing the
image in normal job or MUSIC (line position adjustment) for start position [M].
See SC230-001for troubleshooting details.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
230
-004
D FGATE ON error: C
The PFGATE ON signal does not assert within 5 seconds after processing the
image in normal job or MUSIC (line position adjustment) for start position [C].
See SC230-001 for troubleshooting details.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
231
-001
D FGATE OFF error: K
• The PFGATE ON signal still asserts within 5 seconds after processing the
image in normal job or MUSIC (line position adjustment) for end position
[K].
• The PFGATE ON signal still asserts when the next job starts.
See SC230-001 for troubleshooting details.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
231
-002
D FGATE OFF error: Y
• The PFGATE ON signal still asserts within 5 seconds after processing the
image in normal job or MUSIC (line position adjustment) for end position
[Y].
• The PFGATE ON signal still asserts when the next job starts.
See SC230-001 for troubleshooting details.
SC Tables
567
