Ricoh Aficio SP C440DN User Manual

No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
- - The machine detects a High signal from the drum/development motor: K for 2
seconds after the drum/development motor: K turned on.
• Overload on the drum/development motor: K
• Defective drum/development motor: K
• Defective harness
• Shorted 24 V fuse on the PSU
• Defective interlock system
1. Check or replace the harness.
2. Check if torque output value for drum/development motor is proper if not
replace the unit.
3. Replace the drum/development motor: K.
4. Replace the 24V fuse on the PSU.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
397 D Drum motor error: CMY
- - The machine detects a High signal from the drum motor: CMY for 2 seconds after
the drum motor: CMY turned on.
• Overload on the drum motor: CMY
• Defective drum motor: CMY
• Defective harness
• Shorted 24 V fuse on the PSU
• Defective interlock system
1. Check or replace the harness.
2. Check if torque output value for drum motor is proper if not replace the unit.
3. Replace the drum motor: CMY.
4. Replace the 24V fuse on the PSU.
SC Tables
575

Ricoh Aficio SP C440DN Specifications

General

Print Technology	Laser
Resolution	1200 x 1200 dpi
Processor	533 MHz
Supported Operating Systems	Windows, Mac OS, Linux
Weight	32 kg
Print Speed	Up to 42 ppm
Monthly Duty Cycle	150000 pages
Paper Input Capacity	650 sheets
Connectivity	USB 2.0
Paper Sizes	A4, A5, A6, B5, Legal, Letter, Executive
Dimensions	40 cm x 52.85 cm x 42 cm
