Use the table below to determine which color is affected.
Examples:
• SC681-06 > K
• SC681-27 > C
• SC681-24 > Y
RFID_AFE Board (KMCY)
K C M Y
-06 -07 -08 -09
-11 -12 -13 -14
-16 -17 -18 -19
-21 -22 -23 -24
-26 -27 -28 -29
-31 -32 -33 -34
-36 -37 -38 -39
-41 -42 -43 -44
-46 -47 -48 -49
-51 -52 -53 -54
-56 -57 -58 -59
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
682 D Memory chip at TD sensor: Communication error
Retry of memory chip communication fails three times after the machine has
detected the memory chip communication error.
• Damaged memory chip data
• Disconnected inter face
• No memory chip on the development unit
• Noise
Replace the PCDU.
SC Tables
597
