Ricoh Aficio SP C440DN

6. Install the edge clamp [A] and the six clamps.
7. Connect the relay harness [A] to the heater harness [B] ( x 4).
8. Route the relay harness [A] as shown above ( x 3).
• Make sure that the connector [B] is placed securely as shown above.
2. Installation
66
