If using the red GF15 PVC pulse/litre counter, you can use the following table:
DN K-factor
15 128,450
20 64,160
25 39,270
32 22,490
40 13,700
50 7,860
65 4,620
80 3,300
100 2,150
150 1,080
<M> Settings / Unit / Characteristics
Number of drain groups in use
Here you enter the number of drain groups that are in
use. This number may be smaller than or equal to the
number entered in the system configuration.
Number of drain tanks in use
Here you enter the number of drain water tanks that
are in use. This number may be smaller than or equal
to the number entered in the system configuration.
Number of disinfected tanks in use
Here you enter the number of disinfected water tanks
that are in use. This number may be smaller than or
equal to the number entered in the system
configuration.
Type of disinfection control
l Dose: Disinfection based on radiation dose
control. A flow rate is calculated based on the
preset radiation dose and the measured
radiation level.
l Calibration curve: Disinfection based on a
calibration curve. The flow rate is calculated
based on the measured radiation level and the
calibration curve.
Calibration curve
VitaLite
70
