<M> Settings / Unit / Characteristics
Max. radiation measurement [mW/cm2]
Here you enter the radiation intensity that
corresponds to a 20mA signal from the radiation
sensor.
Supply water transmission [%]
Here you enter the transmission value of the supply
water to be disinfected. This is measured using a
transmission measuring case.
Use T10 meas. for I average
Here you indicate which T10 value is to be used to
calculate the average radiation intensity.
l Yes: The T10 value measured by the T10
sensor.
l No: The T10 value measured with a
transmission measuring case and has been
entered manually.
Only relevant when
disinfection is based
on 'dose' (i.e. the
radiation dose).
Run time drain valve [hh:mm:ss]
This sets the run time of the drain valve that controls
the supply of water from a drain tank. When a process
is initiated, this is the duration that the unit will wait
until the valve is correctly positioned.
Disinf. valve monitoring active
l Yes: If the unit fails to detect that the valves
have closed during the 'Run time disinfected
valve', then the alarm message 'Disinfected
valve is leaking' will be generated.
l No: Monitoring is disabled.
Run time disinfected valve [hh:mm:ss]
This sets the run time of the disinfected valve
controlling the supply of water to a disinfected tank.
When a process is initiated, this is the maximum
duration that the unit will wait for the valves to close.
(The contacts of these valves are arranged in series.)
See also: 'Disinf. valve monitoring active' in this
section.
K-factor total flow [p/l]
Here you enter the K-factor in pulses/litre as specified
by the manufacturer of the flow sensor. This factor
depends on the diameter of the tube in which the
sensor has been installed.
See K-factor table at
the start of this
section.
VitaLite
71
