Remote Control
R&S
®
RTM20xx
406User Manual 1317.4726.02 ─ 01
● CAN - Configuration..............................................................................................406
● CAN - Trigger........................................................................................................407
● CAN - Decode Results..........................................................................................411
● CAN - Search........................................................................................................417
CAN - Configuration
BUS<b>:CAN:DATA:SOURce.........................................................................................406
BUS<b>:CAN:TYPE.......................................................................................................406
BUS<b>:CAN:SAMPlepoint.............................................................................................406
BUS<b>:CAN:BITRate...................................................................................................407
CHANnel<m>:THReshold:FINDlevel................................................................................407
BUS<b>:CAN:DATA:SOURce <Source>
Sets the source of the data line. All channel waveforms can be used.
Suffix:
<b>
.
1..4
Selects the bus.
Parameters:
<Source> CH1 | CH2 | CH3 | CH4 | D0..D15
*RST: CH1
BUS<b>:CAN:TYPE <SignalType>
Selects the CAN-High or CAN-Low line. CAN uses both lines for differential signal trans-
mission.
If you measure with a differential probe, connect the probe to both CAN-H and CAN-L
lines, and set the type CANH.
If you use a single-ended probe, connect the probe to either CAN_L or CAN_H, and select
the data type accordingly.
Suffix:
<b>
.
1..4
Selects the bus.
Parameters:
<SignalType> CANH | CANL
*RST: CANH
BUS<b>:CAN:SAMPlepoint <SamplePoint>
Sets the position of the sample point within the bit in percent of the nominal bit time.
See also: "Sample point" on page 186
Suffix:
<b>
.
1..4
Selects the bus.
