CH EDIT Window
109
Parameter Area of the SENDS Tab
Send point
SEND PAN
PAN LINK
Send level
ON
SEND PAN
Send pan to AUX
* This is displayed when the AUX is stereo.
PAN LINK
When PAN LINK is on, PAN to MAIN and SEND
PAN are linked.
* This is displayed when the AUX is stereo.
Send level Send level sent to AUX
Send point
Selects from among the following as the send
point from input channel to AUX.
5 PRE-P
Pre-processing
5 PRE
Pre-fader
5 POST
Post-fader
* To change the send point, press the [SHIFT]
button, then go to the knob section area and
use the buttons or selected button to perform
the operation.
ON
Turns sending to AUX on/o.
Pressing and holding this sets the send level to
0.0 dB.
Memo
You can work with all 8 parameters at once by holding down the
[ALL] button and turning a knob or pressing a button.
ALL CH SEND POINTS Window
In the ALL CH SEND POINTS window, you set send points to an AUX
for all input channels at one time.
KEEP Keeps the current send point settings.
PRE PROC
Sets all input-channel send points to pre-
processing.
PRE FDR Sets all input-channel send points to pre-fader.
POST FDR Sets all input-channel send points to post-fader.
CANCEL
Cancels any changes to send points and quits the
ALL CH SEND POINTS window.
SET
Applies the changes to send points and quits the
ALL CH SEND POINTS window.
All input-channel send points change.
