Overview of Input Channels/Output Buses
Types of Input Channels/Output Buses
You can select from among the following types of input channels and output buses for the M-5000’s mixing engine.
Input channels
5 INPUT CHANNEL (MONO/STEREO)
Output buses
5 MAIN (MONO/LR/LCR/CROSS-MATRIX LCR/5.1)
5 SUBGROUP (MONO/STEREO)
5 AUX (MONO/STEREO)
5 MIX-MINUS (MONO/STEREO)
5 MATRIX (MONO)
You make the settings for the types of input channels and output buses and the number of each to use in the MIXER CONFIGURATION window.
0“Changing the Number of Input Channels/Output Buses” (p. 81)
You work with the input channels and output buses in the CH EDIT window.
0“Input Channel and Output Bus Operations” (p. 95)
STEREO/LCR/CROSS-MATRIX LCR/5.1
When input channels or output buses are set to STEREO, LCR, CROSS-MATRIX, or 5.1, the following parameters are identical for all channels in STEREO/
LCR/CROSS-MATRIX LCR/5.1.
5 PREAMP (GAIN/+48V/PAD)
5 D.GAIN
5 BAL
5 HPF/LPF
5 DYN 1/DYN 2 (Excludes the key-in)
5 4-BAND EQ
5 MUTE
5 TO SUBGROUP/MIX-MINUS ON
5 TO SOLO SEL
5 TO SOLO ON
5 TO AUX SEL
5 TO AUX LEVEL
5 TO AUX ON
5 DIRECT OUT SEL
5 DIRECT OUT LEVEL
5 DIRECT OUT ON
