CH EDIT Window

115

PAN/ROUTING Tab

The PAN/ROUTING tab is displayed for SUBGROUP and AUX, and

you can make settings for sending to MAIN and sending to MIX-

MINUS.

The operation procedures are the same as for the CH EDIT window

PAN/ROUTING tab for input channels.

The following specications are dierent.

5 SUBGROUP tab is not displayed.
