GEQ

164

Operating a PEQ Using the Knob Section

1. Use <GEQ SEL 1> through <GEQ SEL 32> to select a GEQ

to work with.

2. Use <BAND 1-4> or <BAND 5-8> to select the range to

work with using the knobs.

3. Use the knob section to work with the range you selected

in step 2.
