Monitor/Solo
173
Selecting the Monitor Source Displayed for SOURCE
SELECTOR
1. In the MONITOR 1/2 SETUP window, tap <SOURCE
SELECTOR ASSIGN> for the setting you want to change.
2. Press the [SEL] button for the input channel or output bus
you want to set.
Tapping <CLEAR> clears the setting at the location you tapped in
step 1.
MEMO
Output-bus monitoring uses the POST FDR signal, and input-
channel monitoring uses the CH TOP signal.
3. Tap <OK>.
SOLO Tab
SOLO CLEAR
This clears SOLO 1 or 2.
It ashes when solo is on.
ADD ON
Puts SOLO 1 or 2 in the ADD ON mode.
When in the ADD ON mode, channels for which
[SOLO] is on are mixed.
LAST
Puts SOLO 1 or 2 in the LAST mode.
When in the LAST mode, only input channels/
output buses whose [SOLO] was turned on most
recently are output.
INPUT CH AFL
Selects the location for sending the solo from the
input channel. If this is on, the post-pan signal is
sent. If this is o, the pre-fader signal is sent.
BUS AFL
Select the location for sending the solo from the
output bus. If this is on, the post-pan signal is
sent. If this is o, the pre-fader signal is sent.
AUTO SOLO CH
Sets the input channels for which solo is
automatically turned on when input-channel solo
is turned on.
This is useful when setting return for reverb or
the like.
IN PLACE Turns Solo in Place on/o.
SOLO1/2 TRIM Adjusts the level for SOLO 1 or 2.
