Roland M-5000 - Displaying the GEQ EDIT Window; Inserting a GEQ; Operating a GEQ Using the Knob Section

GEQ
159
Displaying the GEQ EDIT Window
To display the GEQ EDIT window, go to the HOME screen and tap
<GEQ>.
Inserting a GEQ
1. Use <GEQ SEL 1> through <GEQ SEL 32> to select a GEQ
to work with.
2. Tap <INSERT>.
The INSERT popover appears.
3. Select the input channel or output bus where you want to
insert.
The GEQ is inserted into the selected input channel or output bus.
Operating a GEQ Using the Knob Section
1. Use <GEQ SEL 1> through <GEQ SEL 32> to select a GEQ
to work with.
2. Use <GEQ OVERVIEW> to select the range to manipulate
using the knobs.
5 20Hz-630Hz
5 125Hz-4kHz
5 800Hz-20kHz, GEQ LEVEL
3. Use the knob section to work with the range you selected
in step 2.
Pressing the button resets the setting for each band.
