Rear View Features
Figure 4 shows the rear panel of the ZF7025-EU model. For a description of each
rear panel element, refer to Tab l e 6.
Figure 4. ZF7025-EU rear panel
5 Reset Buttons (left
side)
Refer to “Reset Buttons” on page 20 for details.
Table 6. ZF7025-EU rear panel features
Number Name Description
1 PoE In LAN 5/Uplink Uplink LAN port that supports 802.3af and 802.3at
Power over Ethernet (PoE) input.
2 Punch down Block 110 punchdown block.
3 Pass Through Port Uplink RJ-45 pass through port for the pass through
connection.
