Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex Indoor Access Point 9.8.1 User Guide, 800-70601-001 Rev C 19
LEDs
The LEDs for both the US and EU models are the same. Refer to Tabl e 7 for
descriptions of LEDs and their behaviors. The LEDs are not visible once the AP is
installed.
4 LEDs See Ta b l e 7 for LED descriptions and behaviors.
Table 7. ZF7025 LEDs
LED Meaning
WLAN Green: WLAN service is available.
Off: No WLAN service available.
OPT Not used in this model.
DIR Green: AP is being managed by ZoneDirector.
Off: AP is not being managed by ZoneDirector.
Power Green: On.
Red: Bootup in process.
Off: Off.
LAN5/Uplink Green: Link up.
Flashing green: Activity.
Off: Link down.
LAN1 - LAN4 Green: Link up.
Flashing green: Activity.
Off: Link down.
Table 6. ZF7025-EU rear panel features (Continued)
Number Name Description
