Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex Indoor Access Point 9.8.1 User Guide, 800-70601-001 Rev C 23
LEDs
Refer to Tabl e 10 for descriptions of LEDs and their behaviors. The LEDs are not
visible once the AP is installed.
Table 10. ZF 7055 LEDs
LED Meaning
PWR
Green: On
Red: Bootup in process
Off: Off
WAN
Green: Link up.
Flashing green: Activity.
Off: Link down.
5G
Off: The WLAN service is down.
Amber: The WLAN is up, but no clients are associated and no
downlink MAPs are connected.
Green: The WLAN is up and at least one client is associated. No
downlink MAPs are connected.
Slow flashing green (one flash every two seconds): The WLAN is
up and at least one downlink MAP is connected. No clients are
associated.
Fast flashing green (two flashes every second): The WLAN is up,
at least one downlink MAP is connected, and at least one client is
associated.
2.4G
Off: The WLAN service is down.
Amber: The WLAN is up, but no clients are associated and no
downlink MAPs are connected.
Green: The WLAN is up and at least one client is associated. No
downlink MAPs are connected.
