Ruijie RG-WLAN Series User Manual

Configuration Guide Configuring FAT APs
Working Principle
 autowifi
Configuration on an AP:
(1) VLAN planning: VLAN 10 is used as the VLAN for STAs on the AP.
(2) Address pool: The 192.168.110.0 segment is used as the STA address pool on a FAT AP. The IP address of bvi 1 is
192.168.110.1.
(3) WLAN configuration: autowifi_XXXX is used, where the last four characters are the last four characters of the equipment's
MAC address. wlan-id 1 is used.
(4) Security: WPA2 is used for encryption by default. The password is autowifi.
(5) wlan-vlan mapping: VLAN 10 is encapsulated and wlan-id 1 are configured on the RF interfaces of the AP.
(6) Service: the DHCP service is enabled.
1.4 Configuration
Configuration
Description and Command
Configuring a WLAN
(Mandatory) It is used to configure an SSID.
ssid
Configures an SSID.
(Optional) It is used to configure whether to broadcast SSIDs.
broadcast-ssid
Configures whether to broadcast SSIDs.
(Optional) It is used to configure the multicast rate.
mcast-rate
Configures the multicast rate.
Configuring a dot11radio
Subinterface
(Mandatory) It is used to create a dot11radio subinterface and configure the attributes of
the dot11radio subinterface.
encapsulation
Configures the VLAN encapsulated by the
dot11radio subinterface.
wlan-id
Configures the WLAN ID of the mapped
dot11radio subinterface.
Configuring RF Parameters
(Optional) It is used to configure RF parameters.
beacon dtim-period
Configures the DTIM period.
apsd
Enables/disables the U-APSD power-saving
mode.
ampdu
Enables/disables the A-MPDU aggregation
mode.
rate-set 11a
Configures the 11a rate set.
