Ruijie RG-WLAN Series User Manual

Configuration Guide Configuring LLDP
Verification
Display LLDP status information on the interface.
Ruijie(config-if-GigabitEthernet 0/1)#show lldp status interface gigabitethernet 0/1
Port [GigabitEthernet 0/1]
Port status of LLDP : Enable
Port state : UP
Port encapsulation : Snap
Operational mode : RxAndTx
Notification enable : NO
Error detect enable : YES
Number of neighbors : 0
Number of MED neighbors : 0
5.4.12 Configuring the LLDP Network Policy
Configuration Effect
 Configure the LLDP Network Policy.
 If a device is connected to an IP-Phone that supports LLDP-MED, you can configure the Network Policy TLV to push
policy configuration to the IP-Phone, , which enables the IP-Phone to change the tag and QoS of voice streams. In
addition to the LLDP Network Policy, perform the following steps on the device: 1. Enable the Voice VLAN function and
add the port connected to the IP-Phone to the Voice VLAN. 2. Configure the port connected to the IP-Phone as a QoS
trusted port (the trusted DSCP mode is recommended). 3. If 802.1X authentication is also enabled on the port,
configure a secure channel for the packets from the Voice VLAN. If the IP-Phone does not support LLDP-MED, enable
the voice VLAN function and add the MAC address of the IP-Phone to the Voice VLAN OUI list manually.
 For the configuration of the QoS trust mode, see Configuring IP QoS; for the configuration of the Voice VLAN, see
Configuring Voice VLAN; for the configuration of the secure channel, see Configuring ACL.
Configuration Steps
 Optional.
 Configure the LLDP Network Policy.
Verification
Displaying the LLDP network policy configuration.
 Check whether the configuration takes effect.
