4
General Specifications
Type of interface Serial point-to-point connector
Operating mode Asynchronous, full-duplex
Standard V28, RS232C, RS423 specification
Handshake *) 2-wire interface: via software (XON/XOFF)
4-wire interface: via Hardware handshake lines
Clear To Send (CTS) and Data Terminal Ready (DTR)
Transmissions rates *) 150, 300, 600, 1200, 2400, 4800, 9600, 19200 baud
Character coding 7-bit ASCII
Parity *) Mark, space, odd, even
Synchronization 1 start bit, 1 or 2 stop bits *)
Data output format *) of the balance 16 or 22 characters
Character format *) — 1 start bit
— 7 bit ASCII
— 1 parity bit
— 1 or 2 stop bits
*) = can be changed by the user
