14
Opening and Closing the Draft Shield Door
If you are loading small objects, open the draft shield
only as far as is absolutely necessary for your
application. This reduces the amount of draft so
your balance will stabilize faster than it normally
would when the draft shield is wide-open.
You have several options for operating the interior draft shield door (4):
– Semi-Automatic Mode (Aperture Angle s 170°) –
Press one of the keys labeled
(22) to have the draft shield door opened or
closed by motor.
The interior draft shield door moves slowly the first time it is opened after connect-
ing the balance to AC power.
– Semi-Automatic with an Aperture Angle of 10° to 140° –
By a "self-teaching function," the draft shield door can "learn" to open automati-
cally to a user-defined aperture angle from 10° to 140°:
To define this angle, move the interior draft shield door (4) to the desired Position.
