15
Checking Variations in Weight - Weight Readout - Code 2 2 4
To store a weight readout as the target weight, press
The target weight is shown in the analog display as a bar graph. The last segment of this bar graph ends exactly below the
equal sign of the checkweighing indication.
lf the weight of a product is "okay," the last segment of the bar graph will be within the tolerance range of the checkweighing
indication.
You can also read the difference from the target weight in digits.
Additional menu codes used in the example:
Function Code
with data ID code 7 2 2
As an alternative, you can select this output
parameter:
Tolerance + target wt. 7 1 2 Target weight only 7 1 3
Application: checking packages with the same contents for completeness
Step/(key lD)/key Readout Data output/printout
,
0.00000 g
Load sample package (e.g.,
blister pkg) with ideal target
weight
+ 42.84162 g
Store: (STO)
+ 1.0 % Lim + 1.0 %
Setp + 42.84162 g
0.00000 g Net
Remove sample package
Checkweigh packages
Checkweighing
indication
Example:
+ 0.21015 g
+ 0.21015 g
Net
N1
+ 0.21015 g
The data ID codes mean
Lim
Setp
N1
+
+
+
1.0 %
42.84162 g
0.21015 g
over/under limits in percent
target weight stored
difference in weight
