Computer-Controlled Operation of the Draft Shield
Control Commands for the Draft Shield
ESC w 0 CR LF
Draft shield Status (polling)
ESC w 1 CR LF
Open draft shield (aperture angle -170°)
ESC w 2 CR LF
Close draft shield
ESC w 3 CR LF
Open draft shield as far as stored position (see also
"Installation and Operating Instructions" in "Part l")
Each control command with the lower-case letter "w" must be terminated by an underline (ASCII = 5F Hex).
Draft Shield Status
Polling the draft shield Status is done to control the motor-driven draft shield door.
The draft shield Status will not be indicated until all movement of the draft shield door has completely stopped (draft shield
motor "off").
Data Output Formats for the "Draft Shield Status"
These depend on the particular menu code setting:
code 7 2 1 "no data ID code" = data Output with 16 characters
or
code 7 2 2 "with data l D code" = data Output with 22 characters
Data Output Format with 16 Characters
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
* * * * * * W * 0 X X Y Y Y CR LF
*
= Space
Data Output Format with 16 Characters
With this format, the ID code "Stat" is Output in the 1
st
through the 4
th
places.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
S t a t * * * * * * * * W * 0 X X Y Y Y CR LF
*
= Space
