Checking Variations in Weight Code 2 2 4
- Readout in percent - and Code 2 1 5
To store a readout - displayed as a weight or a percent - as the target value, press
.
The target value is shown in the analog display as a bar graph. The last segment of this bar graph ends exactly below the
equal sign of the checkweighing indication. lf the weight of a product is "okay," the last segment of the bar graph will be within
the tolerance range of the checkweighing indication.
You can also read the difference in weight in digits or as a percent.
Additional menu codes used in the example:
Function Code
With data ID code 7 2 2
As an alternative, you can select this output
parameter:
Tolerance + target wt. 7 1 2
Target weight and reference
weight only
7 1 3 Reference % + ref. wt.
Automatic output
4 2 1
Application: checkweighing finished products with automatic printout of the variations within the tolerance limits
Step/(key ID)/key Readout Data output/printout
,
0.00000 g
Load part that has the
"target weight"
+ 42.84162 g
Press:
STO REF
+ 100 % pRef
Wxx%
+ 100 %
+ 42.84162 g
To store limit for checking the
tolerances: press
STO
0.0 %
1.0
Lim
Setp
+ 1.0 %
+ 42.84162 g
Remove part with ideal target
weight
Checkweigh parts
Checkweighing
indication
Example: + 0.7 % Net Prc1 + 0.7 %
The data ID codes mean
pRef
Wxx%
Lim
Setp
Prc1
+
+
+
+
+
100 %
42.84162 g
1.0 %
42.84162 g
0.7 %
reference percentage
reference weight
over/under limits in percent
target weight stored
calculated variation in percent
