Sartorius mc1 User Manual

13
The draft shield Status consists of control codes and the turning angle of the draft shield. The control codes are identified as
XXX, and the turning angle is designated as YYY
XX = Control Codes for the Draft Shield
The decimal values of bits 0 through 6 are added for the following control codes and Output as a decimal number:
Decimal value Binary value Control code
0
1
0
2
0
4
0
8
0
16
0
32
0
64
2
0
2
1
2
2
2
3
2
4
2
5
2
6
Bit 0 = 0
Bit 0 = 1
Bit 1 = 0
Bit 1 = 1
Bit 2 = 0
Bit 2 = 1
Bit 3 = 0
Bit 3 = 1
Bit 4 = 0
Bit 4 = 1
Bit 5 = 0
Bit 5 = 1
Bit 6 = 0
Bit 6 = 1
No control error
Control error
Draft shield motor "off"
Not implemented
Not implemented
Motorized draft shield, as far as it will turn
"Self-teaching'' function off
"Self-teaching" function on (aperture angle 10° to 140° )
Open draft shield*)
Closed draft shield*)
Slow speed*)
Fast speed*)
Motorized draft shield Operation
Manual draft shield Operation
"Control Error"
The control code for "control error" is Output if the draft shield door has not reached the selected position after one attempt
(for mechanical reasons).
"Speed"
The draft shield door moves slowly in the following cases:
—
during the first motor-driven draft shield movement once the balance has been turned on
—
while closing after you have entered an aperture angle from 10° to 140° in the manual mode ("self-teaching" function)
—
while opening following one unsuccessful attempt to reach the selected position (for mechanical reasons)
For all other functions, the draft shield door moves rapidly.
*) These control codes refer to the previous movements of the draft shield door.
