2
1 Large draft shield cover
2 Small draft shield cover
3 Exterior draft shield element, semi cylindrical
(can be moved by hand)
4 Interior draft shield door, semi cylindrical (can be
moved by motor control or by hand)
5 Interior weighing chamber draft shield (depending
on the balance model)
6 Protective ring
7 Weighing pan
8 Shield disk
9 Levelling food
10 Level indicator
11 Display unit
12 AC jack
13 Menu access switch
14 Data interface port
15 Terminal for connecting an equipotential bonding
conductor
16 Lug for attaching the antitheft locking device
17 Metrological label (only *D1-Models)
18 Manufacturer's label
19 Weight and Information display
20
- function key
21
- function key
22
- draft shield function key
23
- Print key (data transfer)
24
- Tare control
25
- toggle key
26
- Info key
27
- ON/Off key
28
- key
