SATO E series User Manual

Appendix B. Bar Code Specifications
SATO Programming Reference Page B-17
Postnet
COMMAND STRUCTURE <ESC>BP (data)
data =
=
=
=
5 digits ZIP
6 digits for Postnet 37
9 digits for ZIP+4
11 digits for Dlelivery Point Bar Code
CHARACTER SET 1-9 (numeric only)
NOTES 1. Frame bits and check digits added automatically by printer.
2. Bar code width and height are fixed and cannot be changed.
3. If the number of digits sent to the printer as data does not match one
of the formats specified above (i.e. 5, 6, 9 or 11), the command is
ignored and nothing will be printed.
4. If a “-” is included in the data stream (i.e. 84093-1565), it is ignored.
EXAMPLE <ESC>H0100<ESC>V0120<ESC>BP94089
<ESC>H0100<ESC>V0160<ESC>BP123456
<ESC>H0100<ESC>V0200<ESC>BP123456789
<ESC>H0100<ESC>V0240<ESC>BP12345678901

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
