SATO E series User Manual

Section 6: Configuration Commands
Page 6-16 SATO Programming Reference
Test Print
COMMAND STRUCTURE <ESC>TPa
a = 0 Small User test print.
1 Large User test print
2 Small Factory test print
3 Large Factory test print
Example: <ESC>TP3
Placement: In a separate data stream.
Default: None
COMMAND FUNCTION To allow test labels to be printed via software control.
PRINTER INPUT <ESC>A
<ESC>TP2
<ESC>Z
PRINTER OUTPUT
Special Notes
1. A test print can also be initiated via the LCD panel.
Small Factory test print
TBA

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
