SATO E series User Manual

Appendic B. Bar Code Specifications
Page B-18 SATO Programming Reference
Data Matrix
COMMAND STRUCTURE Data Format <ESC>BXaabbccddeeefffghh
aa = Format ID. 01-06 or 11-16. The values 07 and 17 will not
be accepted by the printer.
bb = Error correction level. 00 ,05, 08, 10, 14, 20 or 200. All
other values will be processed as a 00.
cc = Horizontal cell size. 03 - 12 dots/cell.
dd = Vertical cell size. 03 - 12 dots/cell.
eee = Number of cells in one column. Use 000 to optimize.
fff = Number of cell in one row. Use 000 to optimize.
g= Mirror Image
0 = Normal Print
1 = Reverse Print
hh = Guide Cell Thickness. 01-15. 01 indicates normal
type.
Sequential
Numbering
<ESC>FXaaabcccdddeee
aaa = Number of duplicate labels to be printed (001 - 999)
b = Increment or Decrement
+ = Increment
- = Decrement
ccc = Increment/Decrement Steps (001 - 999)
ddd = Sequential numbering start position (001 - 999)
Referenced to left side.
eee = Incremented data length measured from start position (001
- 999)
PRINT DATA <ESC>DCxxx...x
xx..x
=Data

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
