SATO E series User Manual

Section 2: Command Codes
Page 2-52 SATO Programming Reference
Print Length, Expanded
Command Structure <ESC>EX0 Sets the print length to maximum
<ESC>AR Resets the maximum print length to 7" (178 mm)
Example: See above
Placement: Must follow the Start Code command and be in it is own
separate data stream.
Default: <ESC>AR(7”)
Command Function To increase the maximum print length (in feed direction) for a label.
Input to Printer <ESC>A
<ESC>EX0
<ESC>Z
<ESC>A
<ESC>H0050<ESC>V0100<ESC>WB1EXPAND TO:
<ESC>H0050<ESC>V2700<ESC>WB1MAX INCHES
<ESC>Q1<ESC>Z
<ESC>A
<ESC>AR
<ESC>Z
Printer Output
EXPAND TO:
MAX INCHES
Max Length

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
