SATO E series User Manual

Section 2: Command Codes
SATO Programming Reference PN 9001096 Rev. A Page 2-29
Font, Raster
Command Structure <ESC>A<ESC>RDabb,ccc,ddd,nn. . .n
a = A CG Times font style
B CG Triumvirate font style.
bb = Always 00
ccc = Horizontal size (16 - 999 dots or P08 - P72)
ddd = Vertical size (16 - 999 dots or P08 - P72)
nn..n = Data to be printed.
Example: <ESC>RDA00,014,018ABCD
Placement: Within normal command stream.
Default: None
Command Function To print point size characters created using font definitions.
Input to Printer <ESC>A
<ESC>V0100<ESC>H0100
<ESC>RDA00,P28,P28,CG Times
<ESC>V0200<ESC>H0100
<ESC>RDB00,075,075,CG Triumvirate
<ESC>Q1<ESC>Z
Printer Output
Special Notes 1. The “cccc” Horizontal Size and “dddd” Horizontal Size parameters
can be entered either in dots or points, but both parameters must use
the same value types. If point size is used, the point size is preceded
by a “P”.

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
