SATO E series User Manual

Section 2: Command Codes
Page 2-62 SATO Programming Reference
Special Notes 1. A reverse image area is affected by the rotate commands. Therefore,
always assume the printer is in the normal print orientation when
designing and sending the Reverse Image command.
2. If using reverse images with the form overlay, place this command
before the Form Overlay command in the data stream.
3. If the height and width to be reversed contain other than alphanu-
meric data, the area is not printed.
4. If the values specified exceed the maximum ranges, the reverse
image is not created.
5. See Table 1 in Section 1. Programming Concepts for values of Hmax
and Vmax.

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
