The window is automatically displayed with the correct path selection (\US-
B_Disk\Schaerer\TouchIT\Logo) (A).
Only files of a suitable format (png, bmp, jpg) are displayed.
► Activate the required file (B).
► Add the activated file to the TouchIT directory using the [Open] (C) field.
The selected file is added to the TouchIT directory.
The file is now available for selection as a logo in the "TouchIT configuration" menu.
Logo (self mode)
This function is used to add "Logos (self mode)" to the TouchIT directory.
The machine is in standby mode.
► Switch on the machine using the field.
► Insert the USB stick under the TouchIT.
The "Restore / Backup" menu is displayed automatically.
► Select the "Logo (self mode)" menu.
The window is automatically displayed with the correct path selection (\US-
B_Disk\Schaerer\TouchIT\Logo) (A).
Only files of a suitable format (png, bmp, jpg) are displayed.
► Activate the required file (B).
► Add the activated file to the TouchIT directory using the [Open] (C) field.
The selected file is added to the TouchIT directory.
The file is now available as a logo in the "1 Logo" selection parameter in the "Self mode
settings" menu.
Replace slide show
This function adds images for a new slide show to the TouchIT directory.
The machine is in standby mode.
► Switch on the machine using the field.
► Insert the USB stick under the TouchIT.
The "Restore / Backup" menu is displayed automatically.
► Select the "Replace slide show" menu.
See "Configuration" - "TouchIT configuration" in the "3 Logo" parameter on selecting and as-
signing a new standby logo.
Note that the path name of the storage location differs in the 1st generation touch screen (US-
B_Disk) and the 2nd generation touch screen (USB_Mstick).
See "Configuration" - "Self mode settings" - "1 Logo" on selecting and assigning a new logo
for use in self mode.
Note that the path name of the storage location differs in the 1st generation touch screen (US-
B_Disk) and the 2nd generation touch screen (USB_Mstick).
