Schaerer Coffee Art TouchIT - Output test

PASCA_TOUCHIT_EN
V02 | 07.2013
93
www.schaerer.comSystem
Output test
Parameters: Output test
Display text Description Setting range Notes
0) V9 main water valve Actuation of the valve for the water supply.
ON:
 The valve opens and water flows.
OFF:
 The valve is closed and water does
not flow.
On/off -
1) V1 valve brew water Actuation of the brewing water valve.
ON:
 The valve opens and water flows.
OFF:
 The valve is closed and water does
not flow.
On/off -
2) V2 / V15 rinsing milk Actuation of the hot water and milk rinsing
valve.
ON:
 The valves open and water flows.
OFF:
 The valves are closed and water does
not flows.
On/off -
3) V2 hot water Actuation of the hot water valve.
ON:
 The valve opens and water flows.
OFF:
 The valve is closed and water does
not flow.
On/off -
4) V8 inlet steamboiler Actuation of the steam boiler inlet.
ON:
 The valve opens and water flows.
OFF:
 The valve is closed and water does
not flow.
On/off -
5) V3+V12 steam outlet Actuation of the valves for the steam outlet.
ON:
 The valve opens and steam flows.
OFF:
 The valve is closed and steam does
not flow.
On/off -
