SET.11 of 16 SEL-749M Settings Sheets
Logic Settings (SET L Command)
SEL-749M Relay Instruction Manual Date Code 20080918
Date _______________
Group______________
SV TIMER PICKUP (0.00–3000.00 sec)
(Hidden if ESV := N or < 8)
SV08PU := _____________________
SV TIMER DROPOUT (0.00–3000.00 sec)
(Hidden if ESV := N or < 8)
SV08DO := _____________________
SV INPUT EQ (SV)
(Hidden if ESV := N or < 8)F SV08 := _____________________
Output Contacts
OUT101 FAIL-SAFE (Y, N) OUT101FS := _____________________
OUT101 (SV)
OUT101 := ______________________________________________________________________
OUT102 FAIL-SAFE (Y, N) OUT102FS := _____________________
OUT102 (SV)
OUT102 := ______________________________________________________________________
OUT103 FAIL-SAFE (Y, N) OUT103FS := _____________________
OUT103 (SV)
OUT103 := ______________________________________________________________________
OUT401 FAIL-SAFE (Y, N)
(Hidden if I/O expansion card is not included)
OUT401FS := _____________________
OUT401 (SV)
(Hidden if I/O expansion card is not included)
OUT401 := ______________________________________________________________________
OUT402 FAIL-SAFE (Y, N)
(Hidden if I/O expansion card is not included)
OUT402FS := _____________________
OUT402 (SV)
(Hidden if I/O expansion card is not included)
OUT402 := ______________________________________________________________________
OUT403 FAIL-SAFE (Y, N)
(Hidden if I/O expansion card is not included)
OUT403FS := _____________________
OUT403 (SV)
(Hidden if I/O expansion card is not included)
OUT403 := ______________________________________________________________________
OUT404 FAIL-SAFE (Y, N)
(Hidden if I/O expansion card is not included)
OUT404FS := _____________________
OUT404 (SV)
(Hidden if I/O expansion card is not included)
OUT404 := ______________________________________________________________________
