SET.12 of 16 SEL-749M Settings Sheets

Global Settings (SET G Command)

SEL-749M Relay Instruction Manual Date Code 20080918

Date _______________

Group______________

Global Settings (SET G Command)

General

PHASE ROTATION (ABC, ACB)

PHROT :=

RATED FREQ. (50, 60 Hz) FNOM := _____________________

DATE FORMAT (MDY, YMD, DMY) DATE_F := _____________________

Data Reset

TARGET RESET EQ (SV)

RSTTRGT := ______________________________________________________________________

Access Control

DISABLE SETTINGS (SV)

DSABLSET := ______________________________________________________________________
