6.4 Expendable Parts List
Mobile DaRt Operation Manual
6-15
6.4 Expendable Parts List
Expendable Parts are shown as Table. 1. Use specified parts at the part
replacement.
Table. 1.Expendable Parts List
Parts Number Parts Name Rating Recommended
exchange
cycle. (Year)
074-71014-01 Battery *1 2
503-46520-01 Wire Rope For MUX-100D
503-46520-03 Wire Rope For MUX-100DJ
10
511-37058 Wheel,ZP-W1 2
511-37075 Caster,439S-150 2
503-49045 Code reel 2
511-70147 Code reel (LAN) 2
501-78646 CPU backup battery 3
062-65003-02 Collimator lamp 1
503-34889-02 Earth belt 2
036-11143-21 Oring, 4D ss-060 5
072-06033-08 Fuse F1 (On INVERTER UNIT-MUX board) 100A, 600V Slow blow
072-01664-34 Fuse F13 (On CONTROL UNIT MUX chassis) 6.3A, 250V Slow blow
072-01664-15
Fuse F11,F12,F23 (On CONTROL UNIT MUX
chassis)
Fuse F1 (On MUX CHARGE-04A board)
Fuse F6 (On MUX POWER-99 board)
0.5A, 250V Slow blow
072-01664-26
Fuse F1,F2(On MUX POWER-99 board)
Fuse F21,F22 (On CONTROL UNIT MUX
chassis)
2.0A, 250V Slow blow
072-01664-33
Fuse F3,F7,F8 (On MUX POWER-99 board)
Fuse F1 (On MUX CHARGE-04B board)
5.0A, 250V Slow blow
072-01659-83 Fuse F4,F5 (On MUX POWER-99 board) 10A, 250V Slow blow
072-01665-34 Fuse F9 (On MUX POWER-99 board) 10A,250V Slow blow
1
532-23029
Silicon packing (standard plug for the
high-voltage unit)
3 mm thick
2 mm thick packing: 532-23061
1
511-15061-11
Contact pin for replacement (standard plug for
the high-voltage unit)
Contact pin + tool
1
511-15061-13
Mini plug maintenance kit (mini plug for the
X-ray tube unit)
Silicon rubber jacket: 5 pcs
Silicon washer: 5 pcs
Silicon oil: 5 pcs
1
*1 The parts number 074-71014-01 is for 1piece of battery. 20 pieces are needed when replacing batteries.
