3.12 Imaging Unit/Grid Storage Bin
Mobile DaRt Operation Manual
3-19
3.12 Imaging Unit/Grid Storage Bin
The near-side slot is used to store the imaging unit.
The rear slot is used to store the Grid Unit, cassette, grid, and protection screen.
If only cassettes are inserted, up to 3 can be inserted.
CAUTION
If the cassette is inserted in the bin when an image is taken, the film in the
casette may be exposed.
Fig. 3-14 Imaging Unit/Grid storage bin
The rear-side slot
The near-side slot
