Mobile DaRt Operation Manual
3-1
Chapter
3
Descriptions of Each Part
Chapter Contents
3.1 Outside View
3.2 X-ray Control Panel
3.3 Power Supply Panel
3.4 Touch Panel Monitor
3.5 Hand Switch
3.6 Driving Handle Section
3.7 X-ray Tube Operating Section and Collimator
3.8 Operation Handle
3.9 Tube Arm Joint Section
3.10 Main Circuit Breaker and Additional Protective Electrical Earthing
Wire
3.11 CXDI-50G Imaging Unit
3.12 Imaging Unit /Grid Storage Bin
3.13 Apron Hanger
3.14 Switch for activating the emergency brake release function
3.15 Operational State Indicator Lamp
3.16 LAN Cable for external connection
