Chapter 3 Descriptions of Each Part
Mobile DaRt Operation Manual
3-14
3.9 Tube Arm Joint Section
This is the machinery that holds the tube section.
Fig. 3- 10 Tube arm joint section
① Tube arm lock release lever
This lever has the same function as the “Tube arm lock release switch”.
The tube arm can be unlocked by lifting up the X-ray tube assembly while
pressing the “Tube arm lock release lever”.
① Tube arm lock
release lever
Tube arm
j
oint section
