Chapter 3 Descriptions of Each Part
Mobile DaRt Operation Manual
3-20
3.13 Apron Hanger
Apron hanger and Imaging Unit Cable Attachment
X-ray protective apron can be hung on the Apron hanger.
Fig. 3-15 Apron hanger
The Apron Hanger should be placed on the hook opposite the tube support arm.
The hooks on the sides of the column should be used for the cable drape.
Contact your nearest authorized Shimadzu service center when you want to
change the installation position.
CAUTION
Apron hanger may hang on X-ray protective apron only.
Apron hanger's useable hanging weight is less than 7kg.
When the arm is unlocked, do not hang apron on apron hanger.
Pay attention while moving the system while an apron is on the Apron
hanger, especially moving the system over any step, and along a
slope.
Apron hanger
