2.6 Safety Symbols for System
Safety symbols displayed on the system are described below:
Symbol Location Meaning
In name plate on covers alternating current
Inside the instrument, where wiring Earthing function
earth conductor is connected
Inside the instrument, where the Protection earthing
protective earth conductor in the
power cord is connected
In the name plate on covers Safety classification:
Type B
On the power supply panel Power on
On the power supply panel Power off
On warning/caution labels Attention:
Refer to Operation Manual
Inside X-ray tube cover Risk of electric shock
On X-ray tube cover Ionizing radiation
