Chapter 4 How to Operate
Mobile DaRt Operation Manual
4-2
4.1 Operation table
4.1.1 Operation table
The operation and the use function are different according to the state of the
Mobile DaRt.Relation of the state of the Mobile DaRt usual operation and
function are described as follows.Refer to the explanation of the method of each
operation and function for details.
Table 4-1 Operation table of Power on/off
Key switch Main breaker
Power on
ＯＮ ＯＮ
Power off
ＯＦＦ
NOTE1
NOTE１：Turn off the key switch and main breaker when the system moves
abnormally.
Table 4-2 Operation table of DR system Start up/Shutdown
Key switch DR switch Shutdown button Main breaker
Start up
ＯＮ ＯＮ ＯＮ
Shutdown Push
NOTE2
NOTE 2：Turn off the key switch and main breaker when the system moves
abnormally.
Table 4-3 Operation table of Battery charge
Key switch
Ｄ
Ｒ
switch Power lead Main Breaker
Battery Charge
ＯＦＦ ＯＦＦ
Connect
NOTE３
ＯＮ
NOTE３
NOTE 3：Disconnect power plug for power outlet and turn off the main breaker
when the system moves abnormally.
