Chapter 3 Descriptions of Each Part
Mobile DaRt Operation Manual
3-8
3.4 Touch Panel Monitor
The Color Touch Panel monitor is controlled by a PC that is mounted inside the
Mobile unit and uses the Windows XP operating system. When the unit is turned
on, the PC will boot and begin CXDI program.
The software can be operated by simple touch the screen in the area of interest.
A finger touch simulates right clicking that area with a mouse curser.
A detail description of the screens can be found in the CXDI series Operation
Manual.
Fig. 3- 4 Touch Panel monitor
CAUTION
Do not place or hang objects on the touch panel. This can lead to touch panel damage.
Do not press on the panel with a sharp, pointed object, subject it to strong
shocks or scratch the panel. These can all lead to touch panel damage or
cause an accident. If the touch panel’s internal liquid leaks from the touch
panel and enters the body, it will have a poisonous effect.
To Next Page
