Chapter 9 Specifications
Mobile DaRt Operation Manual
9-2
9.1 Specifications
MUX-100D MUX-100DJ
Use environment
Atmospheric pressure
7001060hPa
Ambient temperature
1035
Relative humidity
3075%
Common specifications
Total width
580mm
Total length
1250mm
Height of support stand
1930mm 1780mm
Weight 39kg (with imaging unit)
Maximum running speed
5±0.5km/h(this may vary depending on the floor condition.)
Imaging unit storage
1 Imaging unit
Focus height
6002010mm 6001860mm
Arm length
6351200mm
Support stand rotation range ±270deg.
Tube rotation angle ±180deg
Tube rotation around tube axis Forward: 90 deg.; Backward: 20 deg.
Minimum distances between
Focal Spot and Image Receptor
312mm
Power supply
Supply voltage
Built-in battery
For battery drive:
Battery type
Shielded lead storage battery (12 V×20 cells)
Rating of power supply
1kVA
Supply voltage
Single phase AC 100,110,120,200,220,230,240V
Supply Impedance
Single phase AC 100,110,120 V : No more than 1.0Ω
Single phase AC 200,220,230,240 V : No more than 4.0Ω
Supply frequency
50/60Hz
For battery
charge:
Earth resistance
Earth terminal : No more than 100Ω
Additional earth terminal : No more than 100Ω
Power cable length
4m
